中國儲能網訊：隨著筆記本電腦和手機的爆炸式增長，大部分儲能技術的安全重點都集中在移動應用上。這些應用中使用的鋰離子電池在尺寸和密度方面受到更嚴格的限制，可能導致更高的風險。
固定儲能應用通常比移動應用更安全，因為其空間的限制并不相同。但是在一些市場上，空間也可能成為固定儲能面臨的難問題，特別是使用鋰離子電池的項目。
隨著新的安全協議的預期發布，2018年這樣的儲能系統可能會得到更高的評價。
紐約的標準
紐約市就是一個很好的例子。紐約消防局（FDNY）正在制定標準以確保電池儲能項目的安全安裝，但人口密度和官僚機構重疊等因素使紐約成為儲能項目最具限制性的市場之一。
紐約消防局（FDNY）正與紐約州能源研究與發展局（NYSERDA）、美國消防協會、保險公司，以及愛迪生聯合電氣公司合作，致力于制定電池安全的程序和協議。
紐約州能源研究與開發局(NYSERDA)還與愛迪生聯合電氣公司合作制定聯合電池儲能安全計劃，旨在解決紐約消防局和負責審查儲能裝置應用的其他機構面臨的關鍵安全問題。這一舉措是為了支持紐約州州長安德魯?科莫(Andrew Cuomo)的能源愿景改革而開展的，其愿景其中包括通過使用電池儲能來滿足電力高峰需求。
去年5月，紐約市布魯克林區部署了首個功率為300千瓦，電量為1.2兆瓦時的鋰離子電池項目。但是這個項目部署在室外，其消防安全問題沒有得到解決。
紐約的擔憂在存儲市場上有些獨特。其他司法管轄區有安全標準，但是他們的擔心一般還沒有上升到紐約的水平。這可能即將改變。
美國消防協會標準
美國消防協會剛剛制定完成了NFPA 855“固定式儲能系統安裝標準”的草案。該草案可供公眾進行評論。其最終稿將于2019發布和發表，最終版本將在2020年發布。
NFPA 855的發布將在美國全國范圍內制定更嚴格的要求，并可能導致對封閉空間中的儲能位置的總規模得到限制。
“所有具有管轄權的機構都將尊重和維護NFPA發布的標準規范。事實上，他們會很高興，因為這樣他們可以自己的要求做出決定。”DNV GL公司儲能技術總監Davion Hill說。
美國能源部也正在制定能源儲存安全路線圖。許多致力于制定固定儲能安全標準的小組的活動正在由美國能源部桑迪亞國家實驗室（Sania National Laboratory for DOE）開展的項目進行，該項目負責協調NFPA、國際規范委員會和IEEE等代碼設置機構的工作，以及諸如DNV GL和FM Global等公司提供測試并有助于建立規范和標準。
私營公司的標準
一家在安全標準方面具有廣泛影響力的私營公司是美國保險商試驗所（UL），該公司在2014年發布了世界上第一個用于固定儲能的安全標準UL 9540。 UL 9540是其他組織（如NFPA）為制定消防安全或為建筑行業部署儲能標準而制定的具體規范背后做了大部分工作的基本標準。
UL能源和動力技術首席工程師Ken Boyce表示， UL將一直致力于UL 9540的標準工作， UL最近發布了UL 9540A，這是一種評估電池儲能系統熱失控的測試方法。
熱失控是安全專家和消防人員最關心的問題之一。當電池系統中的火災級聯失控時，可能會發生這種情況。
這是紐約市消防部門最為關心的問題之一，同時還有在火災中電池釋放爆炸性氣體的問題，因為電池火災即使在被撲滅后也能重新點燃。
Boyce表示，UL的標準在技術方面是不可知的。它們適用于所有形式的儲能。在實踐中，電池系統并不是唯一可以著火的儲能系統。 2011年，Beacon Power公司在紐約的20兆瓦飛輪儲能設備曾經發生爆炸。
安全不是障礙
總的來說，Boyce表示并不會將安全問題視為儲能項目發展的障礙。隨著標準的不斷發展，其發展將變得更加容易。他說，“我們正在與紐約消防部門密切合作，我們希望看到這項技術向前發展。”
與此同時，Hill說，NFPA 855將改變政府機構允許制度的方式，因為絕大多數制度默認了NFPA，而不是自己制定的規則。事實上，盡管標準仍然以草案的形式出現，一些利益相關者已經從NFPA的發展標準中獲得指導。Hill說，“2020年可能是儲能項目大規模開發的起點?！?strong>（中國儲能網獨家編譯，轉載請注明來源）
Energy storage safety set to move forward in 2018 with new fire standards
New York City and the National Fire Protection Association are developing new safety standards, while UL is updating the world's first such requirements.
Author
Peter Maloney @TopFloorPower
Published
Jan. 2, 2018
Most of the focus on energy storage safety has been on mobile applications, given the spate of exploding laptop and phone batteries.
Lithium-ion batteries used in those applications are under tighter restrictions for size and density that can lead to higher risks.
Stationary storage applications are often safer than mobile uses because there are not the same space constraints. But in some markets, space can also be an issue for stationary storage, especially with projects that use lithium-ion batteries.
Such systems could get a higher profile this year with the expected release of new safety protocols.
New York standards
New York City is a prime example. The Fire Department of New York (FDNY) is working on drawing up standards to ensure the safe installation of battery storage projects, but population density and bureaucratic overlap still make New York one of the most restrictive markets for energy storage projects.
FDNY is collaborating with the New York State Energy Research and Development Authority (NYSERDA), the National Fire Protection Association, insurance companies and Consolidated Edison. Together they are working to come up with procedures and protocols for battery safety.
NYSERDA also is working with Con Ed on a joint battery energy storage safety initiative that aims to answer critical safety questions confronting FDNY and other agencies that are responsible for reviewing applications for energy storage installations. The initiative was undertaken in support of Gov. Andrew Cuomo’s Reforming the Energy Vision, which, among other things, looks to reduce peak demand by using battery storage.
The city saw its first behind-the-meter installation last May — a 300 kW, 1.2 MWh lithium-ion battery project in Brooklyn. But that project is sited outside, where fire safety concerns are muted.
The release of NFPA 855 “will create more stringent requirements nationally” and could result in a cap on the total size of an energy storage location in an enclosed space.
Davion Hill
Energy Storage leader for the Americas, DNV GL
New York’s concerns have been somewhat unique in the storage market. Other jurisdictions have safety standards, but their concerns generally have not risen to the level of New York’s. That may be about to change.
National Fire Protection Association standards
The National Fire Protection Association has just completed a draft version of NFPA 855, Standard for the Installation of Stationary Energy Storage Systems. The draft is available for public comment. The final draft is scheduled for release and comment next year with the final version scheduled for release in 2020.
The release of NFPA 855 “will create more stringent requirements nationally” and could result in a cap on the total size of an energy storage location in an enclosed space.
“All authorities having jurisdiction respect and uphold NFPA. In fact, they will be glad because it relieves them of responsibility for deciding their own requirements,” Hill said.
Nationally, the Department of Energy is also working on an energy storage safety roadmap. The activities of many of the groups working to develop safety standards for stationary energy storage are being focused through programs run by Sandia National Laboratory for the DOE, which coordinates the efforts of code setting agencies such as the NFPA, the International Code Council and IEEE, as well as companies such as DNV GL and FM Global, which provide testing and contribute to establishing codes and standards.
Private standards
One private sector company with wide reach in safety standards is UL, which in 2014 published UL 9540, the world’s first safety standard for stationary energy storage. UL 9540 is the underlying standard behind much of the work being done by other organizations, such as NFPA, to draw up specific codes for fire safety or for deploying energy storage standards for the construction industry.
UL continues to work on UL 9540, Ken Boyce, principal engineer director for energy and power technologies at UL, told Utility Dive. UL recently released UL 9540A, a test method for evaluating thermal runaway in battery storage systems.
Thermal runaway is one of the chief concerns among safety experts and first responders. It can occur when a fire in a battery system cascades out of control.
It's a top concern for New York City fire officials, along with batteries outgassing explosive gases during a fire and battery cells that can re-ignite even after being extinguished.
Boyce says UL’s standards are agnostic with respect to technology. They apply to all forms of storage. And in practice, battery systems are not the only ones that can catch fire. In 2011, Beacon Power’s 20 MW flywheel energy storage facility in New York exploded.
Safety not a barrier
Overall, Boyce doesn’t see safety concerns as a barrier to energy storage development. As standards continue to evolve, development will become “easier and easier,” he said. “We are very engaged with authorities in New York, and we want to see this technology move forward.”
Meanwhile, Hill said NFPA 855 will change the way authorities permit systems because the vast majority of them default to NFPA rather than writing their own rules. In fact, he said some stakeholders are already taking guidance from NFPA’s developing standards. While the standards are still in draft form, “2020 may be the landing spot for projects that are just starting development today,” Hill noted.
